Curt Weight Distribution Shank, 2″ Shank, 14-1/2″ Drop• 17125

Description

This CURT replacement weight distribution shank is compatible with all CURT weight distribution hitches. It can be used to replace a damaged shank or to give your WD hitch greater flexibility in vertical adjustment. It features a standard 2″ shank, multiple mounting options and a high-strength construction that is fully tested for tough jobs and harsh conditions. The 2″ horizontal shank is designed to fit any 2″ x 2″ trailer hitch receiver. This makes it the perfect choice for most CURT class 3 hitches, class 4 hitches or Xtra Duty class 5 hitches. The shank features rounded edges for easier insertion into the receiver tube, and it has a 5/8″ diameter hole to accept a hitch pin or hitch lock for secure mounting in the receiver. This particular weight distribution shank is 20-3/4″ high by 12″ long overall. Each hole in the vertical shank has a 3/4″ diameter, and they are spaced 1-1/4″ apart for a wide range of incremental adjustment of the WD head. With an overall height of 20-3/4″, this WD shank provides a maximum drop of 14-1/2″ (not designed for use in rise position).

• Provides an adjustable mount for any CURT weight distribution hitch
• Rated for 15,000 lbs. gross trailer weight and 1,500 lbs. tongue weight
• Features multiple holes for adjustable head height
• 3/4″ diameter holes are spaced 1-1/4″ from center to center
• Fits 2″ x 2″ hitch receiver tube opening with 5/8″ hitch pin hole
• Constructed from solid steel for reliable strength
• Protected by a durable powder coat finish
• Limited lifetime warranty (one-year finish, one-year parts)
• Includes shank only (weight distribution hitch sold separately)
